LED open light Series #:HX-OF9W-5 Standard LED open light |  |
General:
1. Epoxy shell, 9mm diameter.
2. IP67 waterproof.
2. 8/10mm gray and white wire.
3. Epistar chip F5mm DIP lamp as light source.
Technical:
1. Input: DC5V an power supply is need.
2. Power: 0.1W/pcs.
3. DIP LED as light source.
4. Output: 4lm @pure white 6500K
5. Lifespan: 5000+Hours
Packing:
1. 20/50pcs as a string
2. 50pcs in a anti-static bag.
3. 20~50bags in a carton.
Application:
1. Lighting letter light source.
Installation:
1. Install through the specific hole in the letter.Note:
1. Single color: Red/ Green/ Blue/ Yellow/ White(2700~13000K) all available.
2. Special color like Purple/ Pink/ Orange all available.
3. RGB solution, or RGB with smart IC solution all available in F12mm type!.
|
Highsong single color open light.pdf Size : 171.448 Kb Type : pdf |
